Citrix 1Y0-240 Braindumps 2021

NEW QUESTION 1
Scenario: A Citrix Administrator is running applications on thousands of load-balanced backend servers in a large infrastructure. It is difficult to track and troubleshoot problems due to the large volume of traffic received.
Which feature of NetScaler Management and Analytics System (NetScaler MAS) can the administrator configure to monitor and troubleshoot in detail for an environment of this size?

• A. AppFlow Analytics
• B. Advanced Analytics with Telemetry Node installed
• C. Application Performance Analytics
• D. Application Security Analytics

Answer: B

NEW QUESTION 2
Scenario: A NetScaler is configured with the following modes:
A Citrix Administrator configured a new router and now requires some of the incoming and outgoing traffic to take different paths through the new router. However, the administrator notices that this is failing and takes a network trace. After a short monitoring period, the administrator notices that the packets are still NOT getting to the new router from the NetScaler.
Which mode should the administrator disable on the NetScaler to facilitate the addition of the new router and successfully route the packets?

• A. Layer 3 mode
• B. USIP
• C. MAC-based Forwarding
• D. USNIP

Answer: B

NEW QUESTION 3
Scenario: A Citrix Administrator manages an environment that has multiple websites running through a NetScaler MPX 5550. The NetScaler meets the needs of the environment throughout the year, except in December, when the capacity doubles. The administrator needs to handle this increased web traffic with a temporary, cost-effective solution.
Which action should the administrator recommend in order to handle the increased web traffic?

• A. Purchase a license to upgrade the MPX 5550 to a MPX 5650.
• B. Purchase a BurstPack License.
• C. Purchase Universal License.
• D. Purchase NetScaler Gateway Platform License.

Answer: B

NEW QUESTION 4
Scenario: A Citrix Administrator is executing the following commands on the NetScaler:
add policy dataset Admin_group ipv4
bind policy dataset Admin_group 192.168.149.10 –index 11 bind policy dataset Admin_group 192.168.149.39 –index 12 bind policy dataset Admin_group 192.168.149.49 –index 13 add responder policy POL_1
“!(CLIENT.IP.SRC.TYPECAST_TEXT_T.CONTAINS_ANY(”Admin_group”))” RESET
bind lb vserver ln_vsrv_www –policyName POL_1 –priority 100 –gotoPriorityExpression END –type REQUEST
What will be the effect of these commands?

• A. All the traffic from users with a source IP address of 192.168.149.10, 192.168.149.39, or 192.168.149.49 will be blocked through the NetScaler.
• B. Only the users with a source IP address of 192.168.149.10, 192.168.149.39, or 192.168.149.49 will be allowed to connect to vserver lb_vsrv_www.
• C. Only the users with a source IP address of 192.168.149.10, 192.168.149.39, or 192.168.149.49 will be blocked when attempting to connect to vserver lb_vsrv_www.
• D. Only the users with a source IP address of 192.168.149.10 or 192.168.149.39 will be allowed to connect to the virtual server.

Answer: B

NEW QUESTION 5
View the Exhibit.

A Citrix Administrator has implemented the HTTP Callout.
Click on the ‘Exhibit’ button to view the screenshot of the command-line interface.
Which part of the configuration is responsible for triggering the call to HTTP Callout server?

• A. –parameters cip(CLIENT.IP.SRC)
• B. sys.http_callout(myCallout1)
• C. –urlStemExpr “”/cgi-bin/check_clnt_from_database.pl”
• D. –headers Request(“Callout Request”)

Answer: D

NEW QUESTION 6
Scenario: A Citrix Administrator has configured an Authentication, Authorization, and Auditing (AAA) action policy to allow users access through the NetScaler. The administrator bound the policy to a specific virtual server.
Which policy expression will allow all users access through the virtual server?

• A. ns_disallow
• B. ns_false
• C. ns_allow
• D. ns_true

Answer: C

NEW QUESTION 7
Scenario: A Citrix Administrator is managing a NetScaler SDX running eight NetScaler instances. The administrator first needs to upgrade the firmware on the instances. However, the administrator is concerned that it needs to be done all at once.
What upgrading flexibility does SDX provide in this scenario?

• A. The NetScaler instance can be upgraded at the SDX management level, allowing all instances to be upgraded at once.
• B. It is NOT possible to upgrade the NetScaler instances to different firmware versions.
• C. The NetScaler instance can be upgraded on an individual basis, allowing all instances to run different firmware versions.
• D. The NetScaler instances have to be upgraded at the same time.

Answer: D

NEW QUESTION 8
Scenario: A Citrix Administrator has configured a Responder policy as follows:
add responder action Redirect_Act respond with “DIAMETER.NEW_REDIRECT(”aaa://host.example.com”)”
add responder policy Redirect_Pol “diameter.req.avp(264).value.eq(”host1.example.net”)”
Redirect_Act
bind lb vserver vs1 –policyName Redirect_Pol –priority 10 –type REQUEST What will be the effect of this configuration?

• A. Response originated from “host.example.net” will be redirected to “host1.example.com”.
• B. Request originated from “host.example.net” will be redirected to “host1.example.com”.
• C. Response originated from “host1.example.net” will be redirected to “host.example.com”.
• D. Request originated from “host1.example.net” will be redirected to “host.example.com”.

Answer: B

NEW QUESTION 9
A Citrix Administrator notices that the NetScaler is sending the IP addresses of all the active services in the DNS response.
The administrator can use the set gslb vserver<name> ______ parameter to avoid this behavior. (Choose the correct option to complete the sentence.)

• A. EDR DISABLED
• B. EDR ENABLED
• C. MIR ENABLED
• D. MIR DISABLED

Answer: D

NEW QUESTION 10
POLICY 1:
add rewrite action ACT_1 corrupt_http_header Accept-Encoding add rewrite policy POL_1 HTTP.REQ.IS_VALID ACT_1
POLICY 2:
add rewrite action ACT_2 insert_http_header Accept-Encoding “”identity”” add rewrite policy POL_2 “HTTP.REQ.IS_VALID” ACT_2
How can a Citrix Administrator bind the rewrite policies to the LB vserver lb_vsrv such that POL_2 is evaluated after POL_1 is evaluated successfully?

• A. bind lb vserver lb_vsrv –policyName POL_1 –priority 110 –gotoPriorityExpression NEXT–type REQUESTbind lb vserver lb_vsrv –policyName POL_2 –priority 100–gotoPriorityExpression END –type REQUEST
• B. bind lb vserver lb_vsrv –policyName POL_1 –priority 90 –type REQUESTbind lb vserver lb_vsrv –policyName POL_2 –priority 100 –type REQUEST
• C. bind lb vserver lb_vsrv –policyName POL_1 –priority 90 –gotoPriorityExpression NEXT–type REQUESTbind lb vserver lb_vsrv –policyName POL_2 –priority 100–gotoPriorityExpression END –type REQUEST
• D. bind lb vserver lb_vsrv –policyName POL_1 –priority 90 –gotoPriorityExpression END–type REQUEST bind lb vserver lb_vsrv –policyName POL_2 –priority 80–gotoPriorityExpression NEXT –type REQUEST

Answer: C

NEW QUESTION 11
Which type of NetScaler monitor can a Citrix Administrator use to check the authentication service of the Active Directory Domain Controller?

• A. The TCP monitor with the LDAP Base DN parameters configured in the Special Parameters.
• B. A custom LDAP monitor with the LDAP Script Name, Base DN, Bind DN, Filter, Attribute and Password parameters configured in the Special Parameters.
• C. The Ping monitor with the Active Directory Domain Controller in the Special Parameters.
• D. The RADIUS monitor with the Base DN, Bind DN, Filter, Attribute and Password parameters configured in the Special Parameters.

Answer: B

NEW QUESTION 12
Scenario: A Citrix Administrator is concerned about the amount of health checks the NetScaler is sending to the backend resources. The administrator would like to find a way to remove health checks from specific bound services.
How can the administrator accomplish this?

• A. Use the No-Monitor option.
• B. Use Service Groups to minimize health checks.
• C. Unbind the current monitor.
• D. Use reverse condition monitoring.

Answer: A

NEW QUESTION 13
Which feature can a Citrix Administrator use to create a consistent set of front-end SSL parameters across multiple SSL virtual servers?

• A. SSL Policy
• B. SSL Profile
• C. SSL Bridge
• D. SSL Offload

Answer: B

NEW QUESTION 14
Users are experiencing resets from the Intranet server website, which is load-balanced through the NetScaler.
Which NetScaler tool can a Citrix Administrator use to troubleshoot the reset issue?

• A. Take a packet trace with nstrace and analyze with WireShark.
• B. View the new nslog from the command-line interface (CLI) to look for packet resets from the NetScaler.
• C. Look in the Event Viewer for packet resets from the NetScaler.
• D. Use the nslog to look for packet resets on the NetScaler.

Answer: B

NEW QUESTION 15
Which three authentication types can a Citrix Administrator use for NetScaler AAA dual- factor authentication? (Choose three.)

• A. TACACS+
• B. RADIUS
• C. ADFS
• D. LINUX
• E. LDAP

Answer: ABE

NEW QUESTION 16
Scenario: User authentication is failing through the NetScaler. A Citrix Administrator checked the Authentication, Authorization and Auditing (AAA) policy, action and virtual server and verified that the correct configuration was in place. The administrator bypassed the NetScaler and the authentication worked.
Which NetScaler utility can the administrator use to troubleshoot the access issue?

• A. aaad.debug
• B. Dashboard
• C. nscon message
• D. nslog file

Answer: A

NEW QUESTION 17
Scenario: A NetScaler appliance is having intermittent issues. A Citrix Administrator is unable to identify the root cause and fix them. The administrator opened a Support ticket and the Engineer assigned to the case requested all the logs and configuration information from the NetScaler.
Which technical support tool can the administrator use to gather all the information on the NetScaler to send to the Support Engineer?

• A. Batch Configuration
• B. Start New Trace
• C. Get Back Trace
• D. Generate Support File

Answer: C
